模具结构零件:mold component/part模胚组件：mold-base components上码模板：top clamping plate,upper clamp base, fixed clamp plate, top plate,cavity Back plate水口板：runner stripper plateA板：A-plate,cavityB板：B-plate,core推板：stripper plate托板：support plate方铁：spacer block,riser，parallel，rail顶针板：ejector retainer plate顶针托板：ejector plate下码模板：bottom clamping plate, lower clamp base, moving clamp plate, bottom plate, core Back plate回针：return pin导柱：guide/leader pin导套：guide bushing中托边：guide ejection pin中托司：guide ejection bushing 成型件：molding parts模肉：main insert上模肉：cavity下模肉：core镶件：insert 上模镶件：cavity insert 下模镶件：core insert slider insert runner insert镶针：insert pin 上模镶针：cavity insert pin 下模镶针：core insert pin行位：slider,slide,cam斜顶：angular lifter,angular ejector直顶：straight lifter, ejector bar, ejector block扃顶：ejector blade, square pin, flat pin司筒(针)：ejector sleeve (pin),sleeve浇注系统：injection 流道：runner 冷流道：cold runner浇口：gate法兰：locating ring,flange唧咀：sprue bushing延长唧咀：extension bushing,extended sprue bushing水口勾针：sprue puller pin, sucker pin水口镶件：runner insert热咀：hot sprue bushing, heater nozzle热流道板：hot manifold接线盒：terminal mounting box热电偶：thermocouple 其它：压块：clamp/clamping block限位开关：limit switch垃圾钉：stop pin支撑柱：support pillar (S.P)顶棍：knock-out, ejector bar/rod脚仔：stand-off，foot顶针：pin承压块：support block, balance block斜边：angle pin, horn pin铲基：heel block, locking heel, heel, wedge行位压片：gib, heel block耐磨片：wear plate锁模片：P/L strap, Safety Strap弹簧：spring销钉：dowel pin垫圈： washer日期章：date stamp,dating insert 浇口：gate直接浇口：direct/sprue gate牛角/香蕉浇口： banana /horn /moon /cashew gate潜浇口：submarine gate, sub-gate隧道浇口：tunnel gate侧浇口：edge/side gate点浇口：pin-point/pin gate搭接浇口：tap/overlap gate扇形浇口：fan gate圆盘浇口：dish gate环形浇口:ring gate缝隙浇口：slit gate 薄膜浇口：film gate 常见词汇：封胶：seal-off碰穿、插穿、枕位：shut-off避空：clearance, gap倒扣：undercut骨位：rib柱位：boss脱模：demoulding,demolding合模力：clamping force, die closing force, locking force, press force避让槽：cut-out排位：lay-out不适用：N/A none available待定：TBD to be decided干涉：interfere/interference松配：loose fit/fitting定模：fixed side, fixed half, cavity, cavity half动模：moveable side, moving half ,core, core half运水：water circuit/loop/line错位：misalignment尺寸不一致：dimension various颠倒：upside down段差：mismatch溢边：overflow飞边：flash, burr 报废：scraped精确定位：accurate alignment断浇口：degating转水口：switching runner/gate ,shut-off gate液动：hydraulic气动：pneumatic缸：cylinder强顶：force ejection撬模坑：pry bar slot冷料井：slag well冷料渣：cold slag排气道：air vent备注：remark,comment,note大小：size尺寸：dimension间距：spacing吨位：tonnage容量：capacity缩水：shrinkage注塑周期：cycle time拔模斜度：draft angle,draft锥度：taper材质：material分模线:parting line,split line尖角: sharp edge降面：descend suface加厚：increase material火山口:crater重心：center of gravity 质心：center of mass，centroid行程：travel, stroke冷却：cooling注塑：injection顶出：ejection抽芯：core pull排气：venting加热：heating填充：filling运水进：Inlet运水出：Outlet操作顺序：sequence of operation尺寸公差：dimension tolerance差值：deviation最大:maximum最小：minimum硬：hard软：soft开粗：rough processing,coarse processing 精加工：fine processing结合线：match line ,welding line可移动的：removeable可替换的：exchangeable, replaceable除非另有说明：unless otherwise specified加硬：hardened氮化：nitrided淬火：quenching回火：tempering退火：annealing正火：normalizing调质：aging treatment自润滑：self-lubricating直的：straight有肩：shoulder 备件：Spare part 库存：storage, warehouse, stock标识：label ,mark双边：double side单边：single side模穴数：cavity number,number of cavity产品名称：part name:产品编号：part number模具编号：mold number客户：customer供应商：supplier,vendor确认：confirm合模高度 ：shut height开模行程：daylight 哥林柱间距：tie bar spacing/distance水平：horizontal垂直：vertical顶棍排位：knock-out pattern公：male母：female等同的：EQV ,equivalent, equal少于：less than多于：more than DFM常用句型 关于产品壁厚分析的句型(Part Wall thickness)： 1．此处壁过厚，易产生缩水，建议减少壁厚。Because of the shrinkage of the thickness, we suggest decreasing the material. 2. 红色区域可能会出现缩水，我们建议对下面的筋位减胶处理。It possible has sink mark in the red position， we suggest decreasing the material of these ribs！ 3.壁厚分析：产品壁厚均匀，平均厚度2.5mm.Wall thickness analysis: uniform thickness, average thickness is 2.5mm. 二、关于拔模分析的句型（Part draft analysis） 1. 产品表面出模斜度小于9度，请确认是否蚀纹。The draft angle is less than 9 degrees, please conform whether they need to grain. 2. 紫色面为前模面，9度拔模分析，如果指示的红色面需要蚀纹请加大红色面的出模角（另一个产品同样存在此问题）Purple surface represent cavity side, 9°draft angle analysis, pls increase demoulding angle of the red face if it need to do texture.(the same as another part) 。 3.前模拔模分析：紫色面是前模面，拔模角为9度，请给出表面蚀纹区域和纹号，谢谢！Draft analysis for cavity: purple surfaces is cavity side, draft angle is 9 degree, please advise texture area and # of texture, thank you! 4. 蓝色面为后模面,所有的绿色面是直身的，建议为绿色面增加1-2度的出模角（另一个产品同样存在此问题）。Blue surface represents core side, all green faces are straight, suggest to make their demoulding angle to 1-2°.(the same as another part) 三、关于排位的句型(Layout) 1. 出模数：1+1No. of cavities :1+1 2.排位:产品排位示意图，出模数为1+1，请确认！Layout: The layout drawing for the part, # of cavities: 1*1,please confirm! 四、关于分型线的句型(Parting lines) 1. 此处做行位会有夹线，是否可以接受。Please confirm whether it is acceptable to have a slider split line if we have a slider in this area. 2.在此面上分模线，是否接受吗？There is a parting line on this side, is that OK? 3.红色线是分型线，请确认！These red lines are parting lines, please confirm! 4.红色线是斜顶夹线，请确认！These red lines are lifter’s lines on the product surface, please confirm! 5. 红色线是分型线，请确认！Red lines represent parting line, pls confirm. 五、关于水口位置的句型（Gate location） 1. 一点牛角入水，流道直径为5mm，水口直径为1mm.One point horn gate, the runner diameter is 5mm, the gate diameter is 1mm 2. 一点热嘴转搭接浇口，请确认.One hot nozzle turn to overlap gate,pls confirm. 3. 扇形水口尺寸：15X1mmGate size:15X1mm 六、关于模具结构分析句型（Mold structure） 1. 行位和斜顶排位及分型线,是否OK?Sliders and lifters layout and split line,Is that ok? 七、关于顶出位置的句型（Ejector pin location） 1.如图所示，产品采用顶针和斜顶顶出，并且具体的顶针及斜顶位置会在设计时适当调整，请确认。Ejector pin and lifter eject the part as indicated, and the position of ejector pin and lifter will be adjusted while design, please confirm. 2. 顶出：顶针+斜顶，顶针将在设计时适当调整。Ejector: pins + lifters , pins will be adjusted during designing. 八、关于问题点的句型（Problem） 1． 产品这个面可否加顶针或顶块？Can we add ejector pins or ejector bar in the face of this part?2． 产品的这个位置不能出模，我们打算做行位。There's an undercut at this position and it needs a slider. 3． 产品里面的这个位置我们打算做斜顶或行位，有问题吗？We will make lifter or slider in this position, will that be a problem?4． 产品的这个位置太小，导致模具钢料太薄，能够加宽这个位置吗？This position is too small and the steel material too thin, can we widen it ?5． 斜顶在运动时会干涉到柱子，能移动这个柱子的位置吗？The lifter interferes with the boss during ejection. Please consider changing the position of the boss.6. 此处有尖钢，容易损坏。 It is easy to be damaged due to the sharp feature。7. 产品壁厚为2mm，为了预防缩水建议将产品的筋位厚度由1mm减到0.8mm，请确认！The wall thickness for the part is 2mm, suggest to change the thickness of rib from 1mm to 0.8mm to prevent sink mark, please confirm. 8. 请将绿色面增加0.5度出模角。Pls make demoulding angle to 0.5 °for the green face. 9．斜顶上的绿色面在斜顶出模方向上无拔模角，建议增加1-2度出模角，请确认并修改产品（另一个产品同样存在此问题）The green face of lifters represent no draft angle for the lifters demoulding direction, suggest to make demoulding angle to 1-2°,pls confirm and modify.(the same as the another part)
